Category：Conveyor Feeding Series
Specifications
1. Variable speed
2. Can be horizontal,tilt and vertical transportation
3. Large conveying capacity
4. Standardized parts
Description
Application
Mobile belt conveyor convey loose materials or granules as well as in the assembly, package production areas for departments of light industry, electron, home appliance, food, tobacco, etc.
Working temperature is between -20 °C and 40°C and the temperature of transported material should be under 50 °C.
Technical Parameters
1. Working Temperature: -10°c to 40°c
2. Material Temperature: low than 60°c
3. Driving Device: electric roller and electric motor
Type | Belt width (mm) | Conveying distance(m)
| Belt speed (m/s) | Roller supporting form | Height (m) | Outside size (mm) | ||||
Parallel carrying idler | Trough carrying idler | A | B |
H | ||||||
Piece/h | t/h | t/h | ||||||||
DY 4031 |
400 | 3 | Parallel carrying idler 0.8
Trough carrying idler 1.6 | 800 | 40 | 80 | 1.2 | 3342 | 880 | 1255 |
DY 4051 | 5 | 5392 | 880 | 1227 | ||||||
DY 4071 | 7 | 1.3 | 7403 | 880 | 1329 | |||||
DY 40101 | 10 | 10420 | 880 | 1323 | ||||||
DY 5051 |
500
| 5 | 1400 | 70 | 145 | 1.6 | 5465 | 980 | 1669 | |
DY 5071 | 7 | 7513 | 980 | 1620 | ||||||
DY 50101 | 10 | 1.77 | 11308 | 1290 | 1802 | |||||
DY 50151 | 15 | 1.6 | 16350 | 1290 | 1646 | |||||
DY 6551 |
650 | 5 | 2600 | 130 | 265 | 1.5 | 5494 | 1150 | 1590 | |
DY 6571 | 7 | 1.5 | 7523 | 1150 | 1554 | |||||
DY 65101 | 10 | 1.8 | 11308 | 1460 | 1852 | |||||
DY 65151 | 15 | 1.85 | 16340 | 1460 | 1884 | |||||
Specification
Features
Belt width range: 400, 500, 650, 800 mm.
Rollers: carbon steel, Q235.
Diameters of roller: 89,108,133,159mm. length as buyer's need.
Spare parts: Belt, rollers, frame, driving drum, direction-change drum, wheels and so on.
